  • Icon in stock   Jinko Solar, 450Wp, N-Type Tiger Neo MONO-FACIAL
    Icon in stock   Jinko Solar, 450Wp, N-Type Tiger Neo MONO-FACIAL 1
    Icon in stock   Jinko Solar, 450Wp, N-Type Tiger Neo MONO-FACIAL 2
    Icon in stock   Jinko Solar, 450Wp, N-Type Tiger Neo MONO-FACIAL 3

    Jinko Solar, 450Wp, N-Type Tiger Neo MONO-FACIAL

    Code: 9701
    Inquire about this item
    87.99 € VAT incl. pcs
    ( 72.72 € VAT excl. )
    In stock.
    1 pcs - Vilniaus warehouse (delivery 2 w.d.)
    0 pcs - European warehouse (delivery 7 w.d.)
    Add to cart

    Before buying/ordering:
    Free delivery when ordering from 1 pallet (36 pcs). If you order a smaller quantity, the transport price is 60 EUR. Contact for more specific information.

  • In Vilnius warehouse
    Present
    Manufacturer
    Jinko Solar
    Brand
    Jinko Solar
    Product code
    JKM450-54HL4R
    Maximum Power, Pmax, W
    450
    Maximum Power Voltage, Vmp, V
    33.21
    Maximum Power Current, Imp, A
    13.55
    Open Circuit Voltage, Voc, V
    39.78
    Short Circuit Current, Isc, A
    14
    Module Efficiency, %
    22.52
    Power Output Tolerance, W
    0 / +3
    Maximum System Voltage, V
    DC1500
    Max Series Fuse Rating, A
    25
    Nominal Operating Cell Temperature, NOCT, °C
    45±2
    Temperature Coefficient of Isc, %/°C
    +0.045
    Temperature Coefficient of Voc, %/°C
    -0.25
    Temperature Coefficient of Pmax, %/°C
    -0.29
    Number of Cells
    108 (2x54)
    Glass thickness, mm
    3.2
    Frame Material
    Anodized aluminium
    Frame Color
    Silver
    Backsheet color
    White
    Junction Box Protection class
    IP68
    Cable thickness, mm²
    4
    Cable length, mm
    400
    Connector type
    MC4
    Number of diodes
    Not specified
    Wind Load, Pa
    4000
    Snow Load, Pa
    6000
    Test conditions
    Air Mass (AM)=1.5, Irradiance(E)=1000W/m², Module Temperature(Tc)=25°C
    Ambient temperature, °C
    -40 / +85
    Items per Pallet
    36
    Size of Pallet, mm
    Not specified
    Weight, kg
    22
    Warranty, Year
    15 Product / 30 up to 85% Power
